Latren elastik clipyo itilize pou fikse ray yo ak plak mare sou travès konkrè. Sèvi ak materyèl la nan asye prentan fòje, klip tren nou yo pwodwi pa pwosesis forge cho.GNEE RAILka devlope ak pwodwi divès kalite klip tren tankou E-type (E1609, E1809, E1817, E2007, E2009, E2055, elatriye), klip tansyon SKL (SKL1, SKL3, SKL12, SKL14, SKL75, elatriye), klip PR, seri vit D, klip kalib, clip nabla. Deenik clip kòm byen ke lòt klip estanda ak ki pa estanda ka Customized pa desen oswa echantiyon.
Kalite Rail Clip soti nan GNEE RAIL
E-type Rail clip
| E-type Rail clip spesifikasyon | |
| Non | E-tip tren clip |
| Materyèl | 60Si2MnA 60Si2CrA 55Si2Mn 38Si7 |
| Dite | 44-48HRC |
| Fatig Lavi | pou Dia.18 se 3 milyon sik san kraze |
| pou Dia.20 se 5 milyon sik san kraze | |
| Sifas | plenn (lwil), oksid nwa, penti koulè oswa selon kondisyon kliyan |
| Estanda | DIN17221, BS970, GB/T1222 |
SKL Rail clip
| SKL Rail clip spesifikasyon | |
| Non | SKL tansyon kranpon |
| Materyèl | 60Si2MnA 60Si2CrA 55Si2Mn 38Si7 |
| Dite | 42-47HRC |
| Fatig Lavi | pou Dia.18 se 3 milyon sik san kraze |
| pou Dia.20 se 5 milyon sik san kraze | |
| Sifas | plenn (lwil), oksid nwa, penti koulè oswa selon kondisyon kliyan |
| Estanda | DIN17221, BS970, GB/T1222 |
Nabla Rail kranpon
| Nabla Rail clip spesifikasyon | |
| Non | Nabla rail clip |
| Materyèl | 60Si2MnA |
| Dite | Hrc41-48 |
| Gwosè | Kòm desen ou a |
| Sifas | plenn (lwil), oksid nwa, penti koulè oswa selon kondisyon kliyan |
| Estanda | DIN17221, BS970, GB/T1222 |
Deenik Rail clip
| Deenik Rail clipspesifikasyon | |
| Non | Deenik rail clip |
| Materyèl | 60Si2CrA 55Si2Mn 38Si7 |
| Dite | 42-47HRC |
| Fatig Lavi | pou Dia.18 se 3 milyon sik san kraze |
| pou Dia.20 se 5 milyon sik san kraze | |
| Sifas | plenn (lwil), oksid nwa, penti koulè oswa selon kondisyon kliyan |
Crane Rail clip
| Crane Rail clip spesifikasyon | |||
| Clip No. | Sèvi ak seksyon tren yo | Kalite ￠ a ￠ nan twou | Dyamèt A - 325 Egzagòn tèt boulon machin |
| #114 | 20# ASCE - 40# ASCE | Baz tren + 1" | 5/8" |
| #120 | 25# ASCE - 40# ASCE | Baz tren + 2 1/2" | 3/4" |
| #103 | 40# ASCE - 100# ZÒN | Baz tren + 1 1/4" | 3/4" |
| #106 | 60# ASCE - 100# ZÒN | Baz tren + 2" | 3/4" |
| #62 | 80# ASCE - 175# CR | Baz tren + 1 1/2" | 1" |
| #175 | 175# CR | 8 1/4" | 1" |
Kalite Ris ray klip
| Kalite Ris ray klipspesifikasyon | ||||
| Dyamèt (mm) | Pwa (Kg) | Chaj zòtèy (Kgf) | Materyèl | Sifas |
| 12 | 0.18 | 200~400 | 60Si2MnA 60Si2CrA 5Si2Mn 38Si7 | Plain lwil oliv, oksijèn nwa, zenk plake, plonje cho galvanize, oswa selon kondisyon kliyan |
| 14 | 0.3 | 400~600 | ||
| 16 | 0.44 | 500~700 | ||
| 18 | 0.59 | 800~1000 | ||
| 20 | 0.76 | 1100~1400 | ||
GNEE RAILofri diferan kalite tren Fastener pou satisfè kondisyon kliyan yo, tankou Elastik Rail Clip ak kranpon, Rail Screw Spike, plastik Dowel, High Tensile Track Bolt ak nwa, Rail Base(Tie) Plak, Rail Fish Plate, Railway Shoulder (Insert), Fish Bolt, Railroad Rubber ak EVA Pad, elatriye.
