E-Clip Rail Fastening System
E-Clip Rail Fastening System la se yon kalite sistèm fixation tren souvan itilize atravè lemond. Li fèt pou byen kenbe tren an an plas, bay kontrent longitudinal epi asire estabilite. Sistèm E-Clip itilize yon clip asye prentan ki enstale sou baz tren an, fè presyon pou kenbe tren an an pozisyon.
E-Clip Rail Fastening System konpozan
Konpozan yo nan yon E-Clip Rail Fastening System anjeneral gen ladan:
E-Clips: Klip asye prentan ki fè presyon sou baz tren an pou kenbe l an plas.
Plak Clamping: Bay plis sipò ak estabilite pou E-Clip la.
Izolan: Anpeche konduktiviti elektrik ant tren an ak sistèm nan fixation.
Kawotchou kousinen: absòbe vibrasyon epi redwi bri ant tren an ak sistèm fixation la.
Screw Spike oswa Dog Spike: Secure tren an ak sistèm fixation nan travès la oswa mare.
Plak baz: Distribye chay ki soti nan tren an ak sistèm fixation nan travès la oswa mare.
Fastener: Boulon, nwa, ak rondelles yo itilize pou sekirize eleman yo ansanm.
.jpg?size=x0 "E-Clip Rail Fastening System Components")
E-Clip Rail Fastening System spesifikasyon
| Atik enkli | Kantite | Materyèl | Gwosè | Remak |
|---|---|---|---|---|
| E clip | 2 | 60Si2MNA, 60Si2CrA | Dia. 16mm, 18mm oswa 20mm (E1809, E2006, E2007, E2009, elatriye | Dite: 44-48HRC |
| Chaj zòtèy: Dia.16mm: 500-700kgf; Dia.18mm: 750-900kgf; Dia.20mm:1100-1400kgf | ||||
| Fatig lavi: 5 milyon sik san kraze | ||||
| Estanda: DIN17221, BS970, GB/T1222 | ||||
| Zepòl | 2 | QT500-7, QT450-10 | Pou UIC54, UIC60, 115RE, BS80lbs, BS100lbs, 50kg tren, 60kg ray, elatriye. | Remak: Dite nan E-clip se 44-48HRC; Chaj zòtèy pou E-clip se 500-700kgf (Dia.16mm); 750-900kgf(Dia.18mm); 1100-1400kgf(Dia.20mm); Fatig lavi E-clip se 5 milyon sik san yo pa kraze DIN17221, BS970, GB/T1222 kalifye E-clip |
| Tren pad | 1 | HDPE, kawotchou oswa EVA | ||
| Izolan | 2 | Nylon ranfòse 66 (PA66) |
